BT300J-3A

Features

◇ Membrane buttons can control start and stop, direction and speed

◇ Can quickly fill and empty function

◇ It can communicate with the host computer

◇ External control signal can control start and stop, direction and speed

◇ Power-down memory function

◇ Leakage protection function

◇ Overheat protection function

Technical parameter

◇ Speed ​​range: 1-300rpm, resolution 1rpm

◇ Direction of rotation: forward/reverse

◇ Adjustment method: membrane button and knob adjustment

◇ Display mode: three-digit LED digital tube displays the current speed

◇ External control interface: start-stop control, direction control, speed control (0-5V/0-10V voltage signal, 4-20mA current signal, 0-10kHz pulse signal are all available)

◇ Communication mode: RS485 half duplex

◇ Applicable power supply: 90-260V AC, 50/60Hz

◇ Work rate: ≤50W

◇ Working environment: ambient temperature 0-40℃, relative humidity <80℃

◇ Dimensions: 237×148×170 (length×width×height) mm

◇ Weight: 3.5kg

◇ Degree of protection: IP31
