BT00-600M

Features

◇ MAX key: with filling and emptying functions

◇ Rotation speed can be adjusted manually or controlled by external control interface

◇ Power-down memory function: After power-on again, it will work according to the state of the last power-off

◇ With RS485 communication function, external control analog quantity and pulse control function

Technical index

◇ Speed ​​range: 1-600 rpm forward and reverse reversible

◇ Speed ​​resolution: 1 rpm

◇ Control mode: knob combined with button, support external signal control and communication control

◇ Display mode: 3-digit LED speed display

◇ External control function: start-stop control, direction control, speed control ((0-5V, 0-10V, 0-10KHZ optional)

◇ Communication interface: RS485

◇ Power-down memory: After power-on, it can continue to work according to the state before power-off

◇ Full speed function: One key to control full speed work, used for filling, emptying, etc.

◇ Dimensions (L×W×H): 237×148×170mm

◇ Applicable power supply: AC 90V-260V

◇ Work rate: ≤100W

◇ Working environment: temperature 0℃-40℃, relative humidity <80%

◇ Degree of protection: IP31

◇ Weight: 3.8Kg
