High IP rate basic peristaltic pump BT300J-2A

Short Description:

Flow rate ranges≤2100ml/min

Industrial peristaltic pump, high IP rate

Suitable for humid and dusty industrial production environment


Product Detail

Product Tags

Product description

Industrial peristaltic pump, high protection level

Suitable for industrial production environments such as dampness and heavy sinking

Product Features

◇ Membrane buttons can control start and stop, direction and speed

◇ Can quickly fill and empty function

◇ It can communicate with the host computer

◇ External control signal can control start and stop, direction and speed

◇ Power-down memory function

◇ Leakage protection function

◇ Overheat protection function

Dimensions

2021092303040490

Technical parameter

◇ Speed range: 1-300rpm, resolution 1rpm

◇ Direction of rotation: forward/reverse

◇ Adjustment method: membrane button and knob adjustment

◇ Display mode: three-digit LED digital tube displays the current speed

◇ External control interface: start-stop control, direction control, speed control (0-5V/0-10V voltage signal, 4-20mA current signal, 0-10kHz pulse signal are all available)

◇ Communication method: RS485 half duplex

◇ Applicable power supply: 90-260V AC, 50/60Hz

◇ Work rate: ≤50W

◇ Working environment: ambient temperature 0-40℃, relative humidity <80℃

◇ Dimensions: 250x160x190 (length x width x height) mm

◇ Weight: 4.32kg

◇ IP: 55

32
